    KDON-1000Y Liquid Oxygen Manufacturing Plant 10ppm O2 Liquid Plant 9 Bars

    Ask Lasest Price
    Brand Name : SASPG
    Model Number : KDON-1000Y/1000Y
    Supply Ability : 50 Sets / Year
    Price : Negotiable
    Certification : ASME/CE/GB
    Delivery Time : 8months-18months
    Payment Terms : L/C, T/T
    • Product Details
    • Company Profile

    KDON-1000Y Liquid Oxygen Manufacturing Plant 10ppm O2 Liquid Plant 9 Bars

    Liquid Oxygen And Nitrogen Plant


    LOX output:1,000Nm³


    1) Liquid nitrogen output/purity:1,000Nm³/h<10ppm O2
    2) Nitrogen product pressure: 16KPa.G
    3) Air capacity: 14,500Nm³/h
    4) Compressor outlet pressure: 9 bars
    5) Starting time: 36 hours
    6) Deriming period: 36 hours
    7) Continuous operation period: 1.5 years

    8) Occupied space: 20m x 20m

    This plant operates on a low pressure cycle and is used to produce pure oxygen and
    nitrogen from air by means of cryogenic rectification.The feed air is first liquified
    by the refrigeration produced by turbo-expander and then rectified for two times on the basis of the different boiling points between liquid oxygen and liquid nitrogen. As
    a result, oxygen at a purity of over 99.6% and nitrogen at a purity of over 99.99% can be obtained from the plant. If required, the plant can also produce liquid oxygen and liquid nitrogen partially by means of modified operation.

    We can also design and produce it with different capacities for you.


    KDON-1000Y Liquid Oxygen Manufacturing Plant 10ppm O2 Liquid Plant 9 BarsKDON-1000Y Liquid Oxygen Manufacturing Plant 10ppm O2 Liquid Plant 9 BarsKDON-1000Y Liquid Oxygen Manufacturing Plant 10ppm O2 Liquid Plant 9 Bars
